Go back to Catalog: Insulated Glass
Sound Proof Double Panel Aluminum Frame Double Glazed Hollow Insulated Glass Technical Parameters
type of glass insulating glass
Thickness of double-glazed glass 3mm + 6A + 3mm, 5mm + 6A + 5mm, 6mm + 9A + 6mm, 6mm + 12A + 6mm, 6mm + 16A + 6mm, etc. 3mm + 6Ar + 3mm, 5mm + 6Ar + 5mm, 6mm + 9Ar
+ 6mm, 6mm + 12Ar + 6mm, 6mm + 16Ar + 6mm, etc.
Glass combination type Tempered insulating glass, laminated insulating glass, low-emissivity insulating glass, frosted insulating glass, screen-printed
insulating glass, etc.
Low E type Double silver low e, triple silver low e, online hard-coated low e: Externally Solarban 60, Solarban 70, Guardian SN54 SN68
SN62/27, Saint-Gobain low e, etc.
Gasket options Stainless steel, aluminum, TGI (thermal insulation gasket), super gasket
Gasket thickness 6mm, 9mm, 12mm, 16mm, 19mm (1/4'', 11/32'', 1/2'', 9/16'', 19/32'', 5/8'') etc.
Gas filling Air, argon, krypton, etc.
Glass color options Transparent, low iron, ultra-white, ultra-white, ultra-white, Starphire, Optiwhite, European grey, dark grey, crystal grey, brown,
bronze, ocean blue, Ford blue, deep blue, etc.
size Custom size, maximum: 18000mm L * 3660mm H (flat), 3300x8000mm (curved or bent)
edge processing Flat edge, seam edge, polished edge, inclined edge, flat polished edge, round edge
irregular shape Rectangular, circular, elliptical, trapezoidal, parallel, etc. All edges can be polished with a bright finish.
Provide holes and notches The edges of simple holes such as blind holes, round holes, flared holes, simple notches, and Mickey ear incisions, etc., can be
precisely polished by CNC.
standard trade terms EXW, FOB, CIF, DDU, etc.
delivery time Generally, it takes 2 to 4 weeks, depending on the order quantity.
payment clause 30% of the payment is made in advance before production, and the remaining 70% is settled via TT upon shipment. L/C
minimum order quantity 100 square meters
texture Glass, insulating glass, low-emissivity glass, laminated glass, bulletproof glass
customization Logo customization, packaging customization, demand customization, performance customization
High Performance Soundproof Double Glazed Aluminum Insulated Glass System

Our sound proof double glazed aluminum frame insulated glass is a premium building envelope solution designed for modern architectural projects that require both acoustic comfort and thermal efficiency. It combines double panel glazing technology with a durable aluminum framing system and hollow insulated glass unit (IGU) structure.

As a professional manufacturer, we provide high-quality insulated glass systems for residential, commercial, and high-rise construction projects worldwide.
