Insulated Glass definition:

Insulated glass is made of three pieces of glass(or twe pieces of glass),  High-strength and high air tightness composite adhesive is used to bond the glass sheet with an aluminum alloy frame containing a desiccant.
Insulated Glass Common categories:

1、 Float insulating glass

2、 Tempered insulating glass

3、 Coated insulating glass

4、 Low-E insulating glass

The insulating glass can be 3, 4, 5, 6, 8, 10 and 12mm thick original sheet glass, and the air layer can be 6, 9 and 12mm thick.
Product name Insulated Glass
Glass composition Float glass, laminated glass, tempered glass,low-E glass,tinted glass etc.
 Color Clear,white,bronze,blue,gray, green, dark green, F-green, sapphire blue,
ocean blue, bronze, dark gray, and golden etc.
Shape 1)semi-circle  2)rectangle  3)arch   4)special shape
Filled Gas  1) air  2) vacuum  3) argon, etc.


Insulated glass characteristic:

① Insulated glass can reduce indoor air conditioning load by using Low-E membrane on the glass surface
Insulating glass can Reduce the load of indoor air conditioning. It can effectively reduce the indoor heat load. If you make a large window, the larger the window, the stronger the energy saving effect.
② Insulated glass can Improve your indoor ambient temperature
Hollow glass can block the large amount of energy generated by solar radiation to the room, prevent the discomfort caused by radiant heat and reduce the glare caused by the sun.
③ Insulated glass can be made into various colors and many different shapes
Hollow glass can be made into many beautiful colors. You can choose and match reasonably according to your needs to obtain better artistic effect.
④ Application of insulated glass
Insulated glass is suitable for various buildings, such as office buildings, exhibition rooms and libraries; There are other special buildings that need constant temperature and humidity, such as computer room, precision instrument workshop, chemical plant, etc.Insulating glass can also insulate heat and cold, which makes it can be used for doors and windows of trains, cars, ships and refrigerators.

Heat insulating glass can also be used for decoration of building exterior wall glass. Its optical performance, thermal conductivity and sound insulation coefficient shall meet the requirements of most countries.Our insulating glass has obtained certification certificates from many countries. Hollow glass can play the role of heat insulation, sound insulation, theft prevention and fire prevention. There is also a vacuum insulating glass, whose sound insulation and heat insulation can reach the laboratory standard! In addition, there are hollow glass. Inert gas and color paint are added between the two pieces of glass, which can be used to reinforce and decorate the beautiful scenery.
Insulating glass can well separate the cold and hot air from the outside. For example, when the outdoor temperature is – 10 ℃, the indoor temperature in front of the window using single-layer glass is – 2 ℃, while the temperature in front of the window using hollow glass is 13 ℃; In the same building structure, if the outdoor temperature is – 8 ℃ and the indoor temperature is 20 ℃, the cold radiation area of 3mm ordinary single-layer glass accounts for 67.4% of the indoor space, while the cold radiation area of double-layer insulating glass (3 + 6 + 3) accounts for 13.4%.

Insulating glass improves the safety performance of glass windows. When the original float glass with the same thickness is used, the wind pressure resistance strength of the hollow glass is 1.5 times that of the ordinary single glass.



Methods for determining the advantages and disadvantages of insulated glass:

“Insulating glass” is not “empty”. Qualified insulating glass interlayer must be filled with inert gas argon or krypton. The test after filling shows that the K value (the limit value of heat transfer coefficient) can be reduced by 30%, which means that the thermal insulation performance is better. If the insulating glass sandwich you buy is really “empty”, it undoubtedly shows that its thermal insulation or thermal insulation and cold insulation performance is only double-layer glass at best, and the efficiency of thermal insulation and energy saving is definitely very low. Scientific tests have proved that qualified insulating glass can reduce the heat transfer coefficient K limit of ordinary window glass from 3.5 to 2.8, and the reduction of heat transfer performance can prevent indoor heat loss. Most of the fake insulating glass on the market are simply fixed together with two pieces of glass, with poor thermal insulation performance.
