Specifications:
|
1. Opinions |
1)We can supply all kinds of steel structures, steel building, metal building, modular house, steel frame for warehouse, workshop, garage etc, steel beams, other riveting and welding parts. |
|
|
2)We can also make and develop new parts according to customers' drawings and detailed dimensions. |
2.Specifications |
1)Size: MOQ is 100m2, width X length X eave height, roof slope |
|
|
2)Type: Single slope, double slope, multi -slope; Single span, double-span, Multi-span, single floor, double floors! |
|
|
3) Base: Cement and steel foundation bolts |
|
|
4) Column and beam: Material Q345(S355JR)or Q235(S235JR) steel, all bolts connection! Straight cross-section or Variable cross-section! |
|
|
5) Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc |
|
|
6) C or z purlin: Size from C120~C320, Z100~Z200 |
|
|
7) Roof and wall panel: Single colorful corrugated steel sheet0.326~0.8mm thick, (1150mm wide), or sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~100mm, |
|
|
8)Accessories: Semi-transparent skylight belts, Ventilators, down pipe, Galvanized gutter, etc |
|
|
9)Surface: Two lays of Anti-rust Painting! |
|
|
10) Packing: Main steel frame without packing load in 40' OT, roof and wall panel load in 40' HQ! |
|
3. Design Parameters |
If you need we design for you, pls supply us the following parameter together with detail size: |
|
|
1)Live load on roof(KN/M2) |
|
|
2)Wind speed(KM/H) |
|
|
3)Snow load (KG/M2) |
|
|
4)Earthquake load if have
5) Demands for doors and windows |
|
|
6)Crane (if have), Crane span, crane lift height, max lift capacity, max wheel pressure and min wheel pressure! |
Steel Shed Building – Durable And Versatile Storage Solution
A Steel Shed Building is a modern, cost-effective and highly durable structure widely used for storage, agricultural, commercial and light industrial applications. Designed with high-strength steel and advanced fabrication technology, steel sheds provide excellent performance compared to traditional wood or concrete sheds.
Unlike conventional wooden sheds that are prone to rot, pests and weather damage, steel shed buildings offer superior strength, longer service life and minimal maintenance requirements. All components are prefabricated in a factory-controlled environment, ensuring precise manufacturing, consistent quality and fast on-site installation.
Steel shed buildings are widely used for equipment storage, farm use, workshops and general-purpose storage due to their flexibility and affordability.
Key Advantages Of Steel Shed Buildings
High Strength And Durability
Steel shed buildings are constructed from premium structural steel, offering excellent resistance to wind, rain, snow and seismic loads. Protective coatings such as galvanization enhance corrosion resistance and extend service life.
Cost Effective Construction
Optimized design reduces material waste and overall construction costs. Prefabrication minimizes labor requirements and shortens project timelines, making it an economical solution.
Fast Installation
All structural components are pre-engineered, pre-cut and pre-drilled before delivery. This allows for quick and efficient assembly on-site, significantly reducing construction time.
Low Maintenance Requirements
Steel sheds require minimal maintenance compared to wooden structures. They are resistant to pests, mold, and decay, reducing long-term upkeep costs.
Flexible And Customizable Design
Steel shed buildings can be customized in size, layout and function to meet different storage or operational requirements.
Main Structural Components
A complete steel shed building system typically includes:
Primary Steel Frame – Main load-bearing structure for stability
Secondary Members – Purlins and girts supporting roof and walls
Roof Panels – Weather-resistant metal sheets or insulated panels
Wall Cladding – Optional enclosed or semi-open side panels
Bracing System – Ensures structural stability under wind and load
Doors And Access Points – Sliding or roll-up doors for equipment entry
Accessories – Gutters, ventilation systems, skylights and drainage
Each component is engineered for strength, durability and long-term performance.
Applications Of Steel Shed Buildings
Steel shed buildings are widely used across multiple industries, including:
Agricultural Equipment Storage
Farm Machinery Sheds
Industrial Storage Facilities
Workshop And Maintenance Sheds
Commercial Storage Units
Residential Backyard Storage Sheds
Their versatility makes them suitable for both small-scale and large-scale applications.
Customization Options
We provide full customization options to meet various project requirements:
Building Width, Length And Height
Roof Styles Such As Gable Or Single Slope
Open-Sided Or Fully Enclosed Designs
Ventilation And Natural Lighting Systems
Wall And Roof Color Options
Additional Storage Bays Or Extensions
Our engineering team provides professional design support and detailed drawings to ensure optimal functionality.
Manufacturing And Quality Control
All steel components are manufactured using advanced CNC cutting machines, automatic welding systems and precision drilling equipment. Strict quality control is applied at every stage of production.
Each steel shed building is carefully inspected before shipment to ensure compliance with international quality and safety standards.
Packaging And Transportation
All components are securely packed and labeled for easy identification during installation. The modular design allows efficient container loading, reducing shipping costs and improving logistics efficiency.
Installation And After-Sales Support
We provide detailed installation manuals and technical guidance for on-site assembly. Remote support is available, and on-site supervision can be arranged for large projects.
Our after-sales team ensures long-term support and customer satisfaction.
Why Choose Our Steel Shed Buildings
Factory Direct Competitive Pricing
Professional Engineering And Design Support
High Quality Steel Materials And Strict Quality Control
Fast Production And Global Delivery
Fully Customizable Shed Solutions
Reliable After-Sales Service
We are committed to providing durable, efficient and cost-effective steel shed building solutions for global customers.
