Product Paramenters
|
BASIC FEATURE(20FT) |
EXTERNAL DIMENSION(MM) |
5900*6320*2480 |
|
FOLDING STATE (MM) |
5900*2200*2480 |
|
TOTAL MASS(KG) |
2900 |
|
BASIC FETAURE(40FT) |
EXTERNAL DIMENSION(MM) |
11800*6320*2480 |
|
FOLDING STATE (MM) |
11800*2200*2480 |
|
TOTAL MASS(KG) |
4700 |
|
OTHER SIZE |
CUSTOMIZED ACCORDING TO REQUIREMENTS |
|
FRAME STRUCURE |
STEEL STRUTURE |
Q235 GALVANIZED STEEL FRAME |
|
MIDDLE ROOF BEAM |
Q235 GALVANIZED STEEL FRAME(2.5-3MM) |
|
MIDDLE BASE BEAM |
Q235 GALVANIZED STEEL FRAME(2.5-3MM) |
|
SIDE BEAM |
Q235 GALVANIZED STEEL FRAME(1.5-2MM) |
|
SIDE WALL FRAME |
Q235 GALVANIZED STEEL FRAME(1.5-2MM) |
|
MIDDLE PILLIAR |
Q235 GALVANIZED STEEL FRAME(2.5-3MM) |
|
SUB- FRAME |
Q235 GALVANIZED STEEL FRAME(1.5-2MM) |
|
PROTECTIVE COATING FOR INTEGRAL FRAME |
ELECTROSTASIC SPRAYING/WHITE PLASTIC POWDER SPRAYING |
|
TOP OF CONTAINER |
EXTERNAL ROOF BOARD |
FIREPROOF AND FLAME-RETARDANT EPS INSULTED SANDWICH PANEL&ROOF CORRUGATED VENEER |
|
INTERNAL CELLING BOARD |
0.25 TYPE-200 CELLING |
|
WALL PANEL |
HEAT PRESERVATION OF MIDDLE TOP |
50MM FIREPROOF AND FLAME-RETARDANT INSULATION SANDWICH PANEL/COLOR STEEL PLATE WITH GLASSFILAMENT COTTON |
|
|
65MM FIREPROOF AND FLAME-RETARDANT INSULATION SANDWICH PANEL/COLOR STEEL PLATE WITH GLASSFILAMENT COTTON |
|
INTERNAL PARTITION |
55M ENVIRONMENTALLY FRIENDLY INSULATION MATERIALS |
|
FLOOR |
MIDDLE FLOOR
|
18MM FIREPROOF GLASS MAGNESIUM BOARD/FIREPROOF CEMENT FIBER FLOORING |
|
FLOOR ON BOTH SIDES |
18MM BAMBOO FLOORING/THICK BAMBOO PLYWOOD |
|
ELECTRICIAL SYSTEM (CUSTOMIZED) |
ELECTRICAL WIRING,INSTALLING IN STRICT ACCORDANCE WITH THE MOISTURE-PROOF SPECIFICATIONS,ALL ELECTRICAL PRODUCTS SHALL COMPLY WITH CERTIFICATION.
CONNECT THE CIRCUIT ACCORDING TO THE CIRCUIT ENGINEERING SPECIFICATION,INDOOR:2 LED LIGHTS,2 CEILIING LAMP,3 FIVE- HOLE SINGLE SOCKET,1 SINGLE SWITCH,3 TEN HOLE SOCKET,1 AIR CONDITIONER SOCKET,1 20A-LEAKAGE PROTECTOR.VOLTAGE 220V,50HZ
|
|
WE CAN CUSTOMIZE CIRCUITS THAT MEET CERTIFICATION REQUIREMENTS ACCORDING TO DIFFERENT COUNTRIES.
|
|
DOOR |
BROKEN BRIDGE ALUMINUM ENTRANCE DOOR (WITH PASSWORD LOCK),BEDROOM METAL SWING DOOR |
|
WINDOWS |
ALUMINUM ALLOY WINDOWS,DOUBLE-LAYER INSULATED TEMPERED GLASS |
Man Camp Housing refers to modular accommodation solutions specifically designed to house large groups of workers in remote and industrial environments. These housing systems are widely used in oil and gas fields, mining operations, construction projects, infrastructure development sites, and disaster relief camps where permanent buildings are not practical. Built using prefabricated modular construction technology, man camp housing provides fast, flexible, and cost-effective living solutions for workforce accommodation needs.
One of the key advantages of Man Camp Housing is rapid deployment. Remote industrial projects often operate under tight schedules and in isolated locations where traditional construction is time-consuming and expensive. Modular man camp units are prefabricated in factories and delivered ready for installation, allowing full camps to be set up in a matter of days or weeks. This significantly improves project efficiency and reduces downtime for large-scale operations.
Durability is a critical factor in man camp environments. These structures are engineered using high-strength steel frames, insulated sandwich panels, and corrosion-resistant coatings to withstand extreme weather conditions. Whether installed in deserts, arctic regions, coastal zones, or mountainous areas, man camp housing is designed to resist wind, rain, snow, heat, and dust while maintaining structural stability over long-term use.
Comfort and livability are essential for maintaining workforce productivity and well-being. Man Camp Housing units are designed to provide a safe and comfortable living environment for workers who may stay on-site for extended periods. Accommodation layouts typically include single or shared bedrooms, dormitory-style units, bathrooms, kitchens, dining halls, laundry facilities, and recreational spaces. Proper insulation, ventilation, and climate control systems ensure a livable indoor environment in all weather conditions.
Flexibility is one of the strongest benefits of modular man camp systems. Units can be configured to accommodate small teams or expanded into large-scale camps housing hundreds or even thousands of workers. Additional modules such as offices, medical clinics, security rooms, storage facilities, and canteens can be integrated seamlessly into the camp layout. This modular approach allows companies to scale infrastructure based on project requirements.
Safety is a top priority in all man camp housing designs. Units are built to meet international safety standards, including fire resistance, structural integrity, electrical safety, and emergency evacuation requirements. Many systems include fire-rated materials, smoke detectors, emergency exits, and secure locking systems to ensure worker safety and compliance with industrial regulations.
Energy efficiency plays an important role in modern man camp housing. Many camps operate in remote areas with limited access to power infrastructure, relying on generators or renewable energy sources. Energy-efficient insulation, LED lighting, solar panels, and low-energy HVAC systems help reduce fuel consumption and operational costs while maintaining comfortable living conditions for workers.
Portability is another key advantage of man camp housing systems. These modular units are designed for easy transportation using standard trucks or container logistics. As projects move from one site to another, entire camps can be relocated and reused, maximizing return on investment and reducing long-term infrastructure costs.
Maintenance is simplified through modular construction design. Individual units can be repaired or replaced without disrupting the entire camp. Plumbing, electrical systems, and HVAC components are designed for easy access and servicing. This reduces downtime and ensures long-term operational efficiency.
Applications for Man Camp Housing extend beyond accommodation. These modular systems are also used for site offices, command centers, security checkpoints, medical clinics, training rooms, dining halls, and recreational facilities. Their versatility makes them a complete infrastructure solution for remote workforce operations.
Cost efficiency is one of the most important benefits of man camp housing. Compared to traditional construction, modular systems significantly reduce labor costs, material waste, and construction time. Additionally, reusable and relocatable designs allow companies to use the same infrastructure across multiple projects, improving long-term ROI.
Modern man camp designs also focus on improving quality of life for workers. Comfortable living spaces, internet access, entertainment areas, and private accommodation options help improve morale and productivity. A well-designed camp environment reduces fatigue and enhances worker retention in remote projects.
Customization options allow companies to tailor man camp housing to specific operational requirements. Layouts can be adjusted based on workforce size, climate conditions, cultural needs, and project duration. Exterior finishes and branding can also be customized for corporate identity or project-specific standards.
Environmental sustainability is increasingly important in industrial housing solutions. Man camp housing systems can incorporate eco-friendly materials, waste management systems, water recycling units, and renewable energy integration to reduce environmental impact while maintaining operational efficiency.
In conclusion, Man Camp Housing provides a reliable, scalable, and cost-effective accommodation solution for remote workforce operations. With fast installation, durable construction, flexible layouts, and strong safety standards, these modular systems are essential for modern industrial projects. Whether used in oil fields, mining camps, or construction sites, man camp housing ensures safe, comfortable, and efficient living conditions for large workforces in challenging environments.
