Hot Sale Tempered Laminated Glass Price Technical Parameters
Tempered laminated glass is produced by adhering two or more pieces of tempered glass together by inyerlayer film like PVB/SGP/EVA. The interlayer film will continue to hold the glass together in the event that it is struck or dropped.
Tempered/ Toughened Laminated Glass is made by use two or more pieces of tempered glass and adhesive interlayer, the tow pieces of glass are bond together with advanced technology. After a PVB interlayer has been placed between the glass sheets, the whole assembly is subjected to heat and pressure. This makes the complete adhesion of the vinyl and the glass. In the event of breakage, the glass fragments remain bonded to the plastic interlayer.
Thickness 3mm 4mm 5mm 6mm 8mm 9mm 10mm 12mm 15mm 19mm for each panel
Color Blue: Sky Blue; Lake Blue; Dark Blue;Light Blue,ocean blue.
Grey: Euro Grey; Dark Grey, Light Grey
Green: F. Green (Light Green), Dark Green
Bronze: Golden Bronze, Red Bronze
Pink,Golden,Clear etc.
Size(mm) 2000*1500 2200*1500 2134*1524 2440*1830 3300*2134 3300*2140 2140*1650 2440*1650 3300*2440 3660*2140 3660*2440
PVB Color Blue,Grey,green ,bronze,pink,etc
PVB Thickness 0.38mm,0.76mm,1.14mm,1.52mm etc
Applicant Door, window, curtain wall, ceiling, floor, partition wall, roof daylighting, show window of the shop and roof window of factory
building. There is extensive application in vehicle, steamer, bank, jeweler’s shop, villa, etc.
Delivery 7-15 days
1. Extremely high safety: The PVB laminated glass withstands penetration from impact. Even if the glass cracks, splinters will adhere to the interlayer and not scatter.
2. Energy-saving building materials: PVB Laminated glass impedes the transmission of solar heat and reduces cooling loads.
3. Create aesthetic sense to buildings: PVB Laminated glass with a tinted interlayer will beautify the buildings and harmonize their appearances with surrounding views.
4. Sound control: PVB Interlayer film is an effective absorb of sound.5. Tempered laminated galas widely used in modern construction, such as window, door, balustrade, shower room, partition, floor, roof, curtain wall, greenhouse etc.
