Fast Assembly container house is originally innovating from portable house. The prefabricated column, beam and panel are shipped as spare parts. Each 40 container can load 15 sets, so it comes with very low freight cost. Because it is shipped as prefab spare parts, crane is not a necessity in the course of discharge and installation. Because of this special feature, it is also friendly for some mountain area construction.
Besides the standard 6M*3M*2.8M dimension, other sizes like 7M*3.5M*3.2M can be made, giving you a more comfortable living space. It has excellent waterproof roof as it adopts a tightly sealed roof design. We have 3 types of fast assembly container houses. The 1st type is Industrial style box design with bolt on lifting corner. The 2nd type is concealed bolts box design. The 3rd type is the double slope or pitched roof design.
Fast Assembly/Detachable container house is especially suitable for the following 2 conditions.
(1)Remote Mountain area without convenient transportation.
(2)For customers who wants more flexible sizes like 7.5M*3.5M*3.2M for a living space.
4. 20 Feet Expandable Container Home Parameters5. Expandable Container House Structure
Outer Dimensions
(L*W*H) |
5800*2400*2896mm |
Inside dimension
(L*W*H) |
5630*2230*2515mm |
|
Thermal insulation performance |
£=0.043W/m.K |
Wind-resistant performance |
0.50KN/ml |
|
Sound insulation performance |
Sound transmission loss2
30dB |
Fire performance |
A-level |
|
Waterproof performance |
II class |
Seismic performance |
Level 8 |
|
Ground live load |
2.0KN/m |
Roof live load |
0.50KN/ml |
|
Structured surface |
Electrostatic spraying white |
Connection method |
High strength bolt connection |
|
Serial Number |
|
Name |
Constituent part |
Number |
Unit |
Notes |
|
1 |
Main frame
(bare steel) |
Top frame |
170mm, top and side beams 2.3mm-2, top crossbeams-2,
purlins of over 50 square steel -6, 20*20*6000 square tubes-2,
and 1 set of explosion-proof wire box. |
1 |
set |
|
|
2 |
Bottom frame |
160mm, bottom side beam 2.3mm -2 supports, bottom
crossbeam -2 supports, purlins of 120 square steel -9 supports |
1 |
set |
|
3 |
Pillar system |
2535*150*210*2.3mm |
4 |
branch |
|
4 |
Top/bottom boX
corner |
|
1 |
set |
|
|
5 |
L-angle |
|
1 |
set |
|
|
6 |
Color steel
topping |
Color steel veneer 360° bite 0.4mm |
1 |
set |
|
7 |
831 ceiling panel |
YX28-277-831,0.3mm |
1 |
set |
|
8 |
Top insulation |
75 thick single foil glass wool 14kg/m + PE film |
1 |
set |
|
9 |
Drainage |
PVC $50*2.0+2700 |
4 |
piece |
|
|
10 |
Floor |
Ground |
18mm glass magnesium plate |
1 |
set |
|
|
11 |
1.5mm PVC plastic flooring |
1 |
set |
|
12 |
Wallboard |
Composite plate |
1150 double-sided 0.30mm-75mm rock wool, with a unit
weight of 50KG/m3,H-port, with orange peel on one side and
plain white on the other, double-sided PE film, |
15 |
piece |
|
13 |
Doors and
windows |
Doors and
windows |
Steel door 840*2035mm |
1 |
door or
window
frame |
|
|
14 |
1110*1120mm-2 plastic steel sliding windows, double push
and double push, equipped with screen windows and anti-theft
guardrails (U-PVC) |
2 |
door or
window
frame |
|
|
15 |
Electrical
equipment |
Light |
LED decorative light 36W*2 |
1 |
set |
16
17 |
Socket
Switch |
10A five hole socket, 3 three hole sockets, 16A, 1 socket
One concealed distribution box with one single button switch |
|
18
19 |
Wire
Industrial socket |
2*1.5m*lighting, 3*2.5m socket, 3*4m* air conditioning
socket, 36m incoming line
220V 50Hz 3P32A |
|
|
20 |
Decoration |
Column wrap
angle |
2535mm color steel molded parts |
4 |
piece |
|
|
21 |
House bottom |
U-shaped flume |
1 |
set |
|
|
22 |
Accessory |
Wall panel
fasteners |
Z-shaped ferrules |
1 |
set |
|
|
23 |
Accessory |
Matching screws, drill tail nails, floor nails, cross half round head |
1 |
set |
|
Multiple Purposes Fast Assemble Prefab Container House is a modern modular building solution designed to meet the growing demand for flexible, efficient, and cost-effective space. Engineered with prefabricated components and a quick assembly system, this type of container house offers outstanding versatility and performance across a wide range of applications.
One of the most significant advantages of this prefab container house is its fast assembly capability. All structural components are manufactured in a factory under strict quality control, ensuring precision and consistency. Once delivered to the site, the unit can be assembled quickly using simple tools, often within a few hours to a few days. This rapid installation process reduces labor costs and project timelines, making it ideal for urgent or large-scale deployments.
The multi-purpose design is another key feature. These container houses can be used for various applications, including residential housing, construction site offices, worker dormitories, classrooms, clinics, retail spaces, and emergency shelters. The flexible structure allows users to adapt the building to different needs without significant modifications.
Durability is a core strength of prefab container houses. Built with high-strength steel frames and insulated sandwich panels, these structures are designed to withstand harsh environmental conditions such as heavy rain, strong winds, and extreme temperatures. Anti-corrosion coatings and weather-resistant materials further enhance longevity, ensuring reliable performance over time.
Customization options make these container houses highly adaptable. Clients can choose from different sizes, layouts, and configurations based on project requirements. Interior spaces can be designed to include bedrooms, offices, kitchens, bathrooms, and storage areas. Additional features such as insulation, electrical systems, plumbing, air conditioning, and modern finishes can be integrated to create a comfortable and functional environment.
Transport efficiency is another important advantage. Many prefab container houses are designed to be compact during transportation, allowing multiple units to be shipped together. This reduces logistics costs and simplifies international shipping, making them an economical solution for global projects.
Cost efficiency is a major factor driving the popularity of these buildings. Compared to traditional construction methods, prefab container houses require less labor, generate less material waste, and have shorter construction timelines. This results in significant cost savings while maintaining high quality and performance.
Sustainability is also a key consideration. These structures are often made from recyclable materials and designed for long-term reuse. Energy-efficient insulation, LED lighting, and optional renewable energy systems contribute to reduced environmental impact and lower operating costs.
Scalability enhances their practicality. Multiple units can be combined horizontally or stacked vertically to create larger complexes. This modular approach allows for easy expansion as needs grow, without requiring extensive reconstruction.
Prefab container houses are widely used across industries such as construction, mining, education, healthcare, tourism, and government infrastructure. Their ability to provide fast, reliable, and adaptable space solutions makes them an essential choice for modern projects.
Ease of maintenance is another advantage. High-quality materials and standardized components simplify repairs and replacements, reducing long-term maintenance costs.
When selecting a multiple purposes fast assemble prefab container house, it is important to consider material quality, insulation performance, customization options, and supplier experience. Working with a professional manufacturer ensures consistent quality and reliable after-sales support.
In conclusion, multiple purposes fast assemble prefab container houses offer a powerful combination of speed, flexibility, and durability. With their quick installation, customizable design, cost efficiency, and wide range of applications, they provide an ideal solution for modern construction needs. Whether for temporary or permanent use, these modular buildings deliver exceptional value and performance.
